BC Instructions and Installations

Please see below for our guides and installations. You can click on the image and print them out as needed.

  • Engineering drawing of typical roadside wood post installation for traffic signs, with detailed dimensions, brace details, cross-sections, and a post spacing table, along with elevation and side view diagrams.
  • Diagram of typical road sign installation showing placement height, lateral positioning, and examples of “Road Work Ahead,” “Detour Ahead,” and “Right Lane Closed” signage, with a chart of taper length criteria by speed.
  • Engineering drawing of laminated wood box post installation, showing detailed dimensions, cross-sections, hardware specifications, and mounting guidelines for traffic signs.
  • Instructional diagram for flagger operations showing proper use of STOP/SLOW paddles, flagger positions, signage placement, buffer zones, and traffic flow during road work.
  • Illustration of crash barrel installation layout with multiple yellow barrels filled to various weights for impact absorption, including a photo of a completed roadside crash cushion installation.
  • Instruction chart of crane hand signals with illustrated workers demonstrating 20 different gestures, including hoist, lower, swing, extend boom, retract boom, and emergency stop.
  • Diagram of a Caltrans flagging plan showing lane closure setup with traffic cones, directional arrows, signage placement, and flagger positions for reversible two-lane highway control.
  • Diagram of a temporary traffic control zone showing termination, activity area, buffer space, transition area, and advance warning area along a roadway, with a conversion chart of inches to millimeters displayed below.
  • Traffic control diagram of a center intersection closure with multiple detour signs, lane closure arrows, “End Road Work” signage, and a sidewalk closure area marked at the bottom.
  • Traffic control plans illustrating bike lane and shoulder lane closures, with signage placement, cones, taper spacing, and directional markings for safe lane management.
  • Roadway diagrams showing left lane and right lane closure setups, including “Lane Closed” and “Road Work Ahead” signage, tapering cones, detour arrows, and work zone markers.
